2025 EARTHWORM CONVEYORS 36X120

2025 EARTHWORM CONVEYORS 36X120 For Sale in Fort Wayne, Indiana at www.hamptonused.com. PIT PORTABLE RADIAL STACKER 36” x 120’ • 48” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice • Low profile tail, (Approximately 42”) • Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims (USED) • Wrap type mid drive- 16” Snub - 3 7/16” Shaft & Roller Bearing • Lagged head 18” Dia., 3 7/16” Shaft & Roller Bearing • 14” Winged Tail, 3 7/16” Shaft & Roller Bearings w/Screw Take-ups • World Wide /WW #6-25 Drive, Motor Mount, Belt Guard • 30 hp, TEFC, 1800 RPM, 230/460 volt • Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers • Pioneer, 5” Returns w/Brackets, 10’ Centers • Belt, 2 Ply, 220 PIW, 3/16 x 1/16 cover • 48” Receiving Hopper w Skirt Rubber, extended sides • Pivot Plate, Tow Hook, weight box (weight not included) • Tail Guard • Primed & Painted, Tool Steel Gray, Unless Specified Differently. Proudly built in the USA with American parts and materials. FINANCE, TRANSPORT AND SHIPPING WORLDWIDE AVAILABLE We Manufacture All Types Of: Radial Stackers, Transfer Conveyors, Channel Frame Conveyors, Truss Frame Conveyors, Jump/Grasshopper Conveyors, Overland Conveyors, Feeder Conveyors. Any Width Or Length. Anywhere In The USA. WE DELIVER.
