2025 EARTHWORM CONVEYORS 8X14

or
Call +1 260 740 8704
Description
2025 EARTHWORM CONVEYORS 8X14 For Sale in Fort Wayne, Indiana at www.hamptonused.com. 8' X 14' HOPPER WITH 30'' BELT FEEDER- 12 CY
These Heavy-Duty Belt Feeders Are Proudly Manufactured Here In The USA and Come With A 2-year warranty. Hundreds have been Sold, Making This a No-Drama Product.
Bin:
• 8’-0” x 14’-0” Bin
o ¼” Reinforced Sides – (12 Cubic Yard)
o Adjustable Feed Gate
o Skirt Board Seal Full Length
o Free Standing Legs with Skids
Feeder:
• Lagged Head 16” Dia., 2 15/16” Shaft & Ball Bearing
• Winged Tail 14” Dia., 2 15/16” Shaft & Ball Bearings w/Screw Take-ups
• World Wide #5-25 Drive, Motor Mount, Belt Guard
• 20 hp, TEFC, 1800 RPM, 230/460 volt
• Pioneer Picking Table Type Rollers on 12” Centers
• Belt, Rubber, 3 Ply, 330 PIW, 3/16 x 1/16 Cover
• Tail Guard
• Primed & Painted With Sherwin-Williams STEEL SPEC 1003/ SHER-KEM
OPTIONS
….24” Feeder
....30” Feeder
…36” Feeder
4 ft Extensions – 4 sides
4 ft Extensions – 3 sides
World Wide – WD4X-150 VFD Variable Speed Drive
Hydraulic Drive
We Manufacture All Types Of: Radial Stackers, Transfer Conveyors, Channel Frame Conveyors, Truss
Frame Conveyors, Jump/Grasshopper Conveyors, Overland Conveyors, Feeder Conveyors. Any Width
Or Length. Anywhere In The USA.
WE DELIVER.
Specifications
| Manufacturer | EARTHWORM CONVEYORS |
| Model | 8X14 |
| Year | 2025 |
| Condition | New |
| Horsepower | 20 HP |
